Page #9 background imageLoading...
Page #9 background image
9
A
C
D
6mm
X4
B
E
G
4mm
X2
5
2. Attach the Seat Frame Assembly to the Seat Rail
NOTICE: Do not crimp the Heart Rate Cable. Once all hardware has been inserted, be sure to fully tighten it.
