8
SPECIFICATIONS / BEFORE ASSEMBLY
Maximum User Weight: 136 kg (300 lbs)
Total Surface Area (footprint) of equipment: 17522.4 cm
2
Power Requirements:
Operational Voltage: 220V - 240V AC, 50Hz
OperatingCurrent: 8A
Maximum Inclined Deck Height: 43.7 cm (17.2 inches)
Assembled Weight: Approx.97.5kgs(215lbs)
Sound Emission: Less than 70 db average without
load. Noise emission under load is higher than without load.
Complies with the following:
ISO 20957 Compliant SAA Compliant
Connectivity:
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a
hard, level surface. Allow a workout area of a minimum 211.3 cm x 396.7 cm ( 83.2” x 156.2” ). Be sure that the workout
space you are utilizing has adequate height clearance, taking into consideration the height of the user and the maximum
incline of the machine.
Basic Assembly Tips
Follow these basic points when you as-
semble your machine:
• Read and understand the “Important
Safety Instructions” before assembly.
• Collect all the pieces necessary for
each assembly step.
• Using the recommended wrenches,
turn the bolts and nuts to the right
(clockwise) to tighten, and the left
(counterclockwise) to loosen, unless
instructed otherwise.
• When attaching 2 pieces, lightly lift
and look through the bolt holes to help
insert the bolt through the holes.
• The assembly can require 2 people.
146.3 cm
( 57.6”)
89.4 cm
196 cm
( 77.2”)
3.97m ( 156.2” )
2.11m
” )
0.6m
( 24” )
2m
( 79” )
0.6m
( 24” )
DO NOT dispose of this product as refuse. This product is to be recycled. For proper disposal of this product,
please follow the prescribed methods at an approved waste center.
