Nautilus T626 Assembly Manual

9
PARTS
15
14
1
3
12
13
4
5
6
7
8
11
10
9
2
16
*
Item Qty Description Item Qty Description
1 1 Console Assembly 10 1 Heart Rate Chest Strap
2 1 Console Backing 11 1 Upright, Left
3 1 Upright, Right 12 1 Handlebar Shroud, Lower Left
4 1 Handlebar Shroud, Upper Right 13 1 Handlebar Shroud, Upper Left
5 1 Handlebar Shroud, Lower Right 14 1 Tray, Left
6 1 Base Shroud, Right 15 1 Tray, Right
7 1
Base Assembly ( * )
16 1 Safety Key
8 1 Base Shroud, Left 17 1 Media Cable (not shown)
9 1 Power Cord 18 1 Silicone Lubricant, Bottle (not shown)
DO NOT CUT the Shipping Strap on the Base Assembly until it has been placed face up as shown in
the appropriate work space ( * ).

Nautilus T626 Specifications

General

Quantity per pack	1 pc(s)
Foldable	Yes
Incline range	0 - 15 %
Maximum speed	19.3 km/h
Minimum speed	0 km/h
Product color	Black, Grey
Number of programs	26
Maximum user weight	136 kg
Backlight color	Blue

Weight and Dimensions

Width	- mm
Weight	- g
Running area (W x L)	20 x 60 mm
Running belt thickness	2 mm
Running deck thickness	25 mm
