7. Connect the I/O Cables, the Earthing Cables and the Remote Speed and Incline Controls Cables
Left side: Connect the Incline remote control cable (9a) to the Console.
Right side: Connect the I/O cable (3b) and Earthing Cable (3c) from the Upright to the Console, and the Speed
remote control cable (3a) to the Console.
NOTICE: Do not crimp the Cables.
9a
9
3b
3a
3
3c
Right side Left side
To Next Page
