Nautilus U618 - Page 18

18
Note: Your machine may not match the image. For reference only.
1. DisconnectandreconnecttheACAdapterfromthewall
outlet to turn the power off and on.
2. Push QuickStart and verify that the console shows that
the default resistance level is 4.
Disconnect all power and allow to sit for 5
minutes.
3. Carefully remove the Seat Post, Left Shroud and Right
Shroud. (Refer to the “Replace the Shrouds” procedure.) Do
not remove the Console and Mast, and keep the Power Inlet
cable (P) in the Shroud connected to the wiring harness on
the motor (D). Slide the Mast Gasket and Top Shroud up the
Mast. Lean the Top Shroud against the Seat Post mount to
keep it clear of the pulley assembly.
Note: It may be necessary to remove the Water Bottle
Holder.
4. Insert2.5”x10”cardboardbetweentheBrakeMagnet
(A)andtheFlywheel(B),andtapethecardboardtothe
Brake Magnet.
Note: Be sure the cardboard covers all of the Brake
Magnet.
5. Turn the power on again.
Machine is on. Current is active. There is risk of
electrical shock.
6. Use the console to set the resistance to the highest
level.ThismovestheBrakeMagnetArm(A1)forward.After
theBrakeMagnetArmstopsatthehighestresistancelevel,
turn power off.
Disconnect all power and allow to sit for 5
minutes.
NOTICE: It is necessary to remove the shrouds for this procedure. Refer to the “Replace the Shrouds” procedure.
P
B
A
D
A1
