TECHNICAL DATA:
RTB PHOENIX BOILERS
Product Name RTB 10 RTB 16 RTB 30 RTB 50 RTB 80
Design Model Phoenix Phoenix Phoenix Phoenix Phoenix
Nominal Performance 11 kW 17 kW 25 kW 48 kW 78kW
Minimum Performance 3 kW 5,5 kW 7,5 kW 14 kW 23 kW
Nominal Efficiency 93,9% 91,1% 91,4% 93,6% 93,6%
Minimum Efficiency 90,5% 92,4% 92,7% 94,6% 93,9%
Power Consumption (Nominal) 37W 40W 90W 168W 125W
Power Consumption (Minimum)
24W 20W 34W 82W 69W
EN303-5:2012 Klasse 5 5 5 5 5
Controller Version: V16 V16 V16 V16 V16
Width (mm) (only boiler) 504 504 655 796 937
Depth (mm) 920 920 926 1192 1396
Height (mm) 1216 1216 1240 1443 1643
Chimney (mm) 100 100 130 150 180
Weight (kg) 222 222 280 470 785
Water volume (liter) 36 36 48 78 105
Ash can (liter) 31 31 38 60 60
Forward/Return/Filling ¾ ” ¾ ” ¾ ” 1” 5/4”
Test # 300-ELAB- 2042 2045 2064 2179 2216
5
