NBE RTB PHOENIX v16.0 - TECHNICAL DATA: RTB PHOENIX HOPPERS

Product Name
RTB Phoenix
300
RTB Phoenix
500
RTB Phoenix
700
SKU
901120 901220 901320
Design Model PHOENIX PHOENIX PHOENIX
Estimated capacity (kgs)* 130 kgs 230 kgs 330 kgs
Capacity (liters) 200 l 350 l 500 l
Width 300 mm 500 mm 700 mm
Depth 1000 mm 1000 mm 1000 mm
Height 1448 mm 1448 mm 1448 mm
Height (w/lid open) 1915 mm 1915 mm 1915 mm
Weight 76 kgs 89 kgs 102 kgs
Compatible w/ RTB 10-30 Phoenix RTB 10-30 Phoenix RTB 10-30 Phoenix
*kilo capacity will vary depending on the density of the pellets
TECHNICAL DATA: RTB
PHOENIX HOPPERS
Product Name 80x80 hopper 80x80 Extension
Double KIT for
NBE hopper
80x80
SKU
300087 300085 300069
Compatible w/ All boilers 80x80 80x80 hopper
Estimated capacity (kgs)* 130 kgs 230 kgs
6
