Enclosure Assembly and Cleaning | 15
Enclosure Assembly and Cleaning
Cable Cover Installation
1. Connect power, control, and video cables before installing the cable cover.
2. Align the cable cover to the cable well recess on the back of the display.
3. Slide the cable cover forward into the recess, with cables positioned under the cut-outs.
4. Slide the cable cover forward until tabs on the bottom edge click into place.
5. If provided, use two thumb screws to secure the cable cover in the upper left and right corners.
Cleaning Instructions
Caution: Prior to cleaning, units should be turned OFF and disconnected from respective power sources.
• Do not allow liquids to enter the interior of the unit, as severe damage to the unit can result.
• Do not use solvents such as benzene or thinner, or any acid, alkaline or abrasive detergents.
Thoroughly wipe all the front glass and plastic enclosure surfaces with a lint free cloth dampened with a mild
glass cleaner such as 70% isopropyl alcohol, distilled 5% acidity white vinegar, or ammonia- or non-ammonia-
based glass cleaners. Do not use harsh solvents, abrasive detergents, or chemical cleaning cloths.
