NDS Radiance Ultra SERIES User Manual

24 | Specifications and Supported Resolutions
Supported Resolutions
DVI Supported Resolutions
SDI Supported Resolutions
VGA, RGBS, and YPbPr Supported Resolutions
Signal Parameter Supported Range
Active Resolution (Horizontal x Vertical) 640 x 480 min to 1920 x 1200 max
Refresh Rate (Vertical Frequency) 23.98 Hz up to 85 HZ
Pixel Clock (Pixel Frequency) 25 MHz up to 165 MHz
The DVI-D input can automatically detect any valid digital DVI signal within the
resolution, vertical refresh, and pixel clock ranges specified in the table above.
Signals outside of any of the specified ranges may not be supported.
Horizontal
Resolution
(pixels)
Vertical
Resolution
(lines)
Vertical
Frequency
(Hz)
Horizontal
Resolution
(pixels)
Vertical
Resolution
(lines)
Vertical
Frequency
(Hz)
720 480i 29.97 1280 720p 59.94
720 483i 29.97 1920 1080sF 24
720 487i 29.97 1920 1080p 24
720 576i 25 1920 1080p 25
720 587i 25 1920 1080p 29.97
1280 720p 24 1920 1080i 25
1280 720p 25 1920 1080i 29.97
1280 720p 30 1920 1080p 50
1280 720p 50 1920 1080p 59.94
Horizontal
Resolution
(pixels)
Vertical
Resolution
(lines)
Vertical
Frequency
(Hz)
Horizontal
Resolution
(pixels)
Vertical
Resolution
(lines)
Vertical
Frequency
(Hz)
Horizontal
Resolution
(pixels)
Vertical
Resolution
(lines)
Vertical
Frequency
(Hz)
720 480i 29.97 640 480 60 1280 960 60
720 487i 29.97 800 600 60.32 1280 1024 60.02
720 480p 59.94 1024 768 60 1600 1200 60
720 480p 60 1280 720p 50 1920 1080i 25
720 576i 25 11280 720p 59.94 1920 1080i 29.97
720 576p 50 1280 960 59.94 1920 1080p 50
1920 1080p 59.94
