System Specifications B-3
Input/Output (I/O) Features
Industry-standard interfaces integrated on system board:
Universal Serial Bus (USB) two USB ports support two USB
peripherals directly to the system. With appropriate connector, the
system supports up to 127 daisy-chained devices. Supports
12 megabits (Mbs) per second.
Parallel bi-directional, ECP/EPP support; one 25-pin connector
Serial one high-speed RS-232C port using a 16550 UART,
supports transfer rates up to 115.2 KB per second; one 9-pin connector
Keyboard PS/2-compatible, 6-pin connector (mini DIN)
Mouse PS/2-compatible, 6-pin connector (mini DIN)
Microphone In supports a microphone or other audio input device
for recording audio information in data files or broadcasting audio
Line In supports input from an external audio device
Headphone — supports external headphone set
IDE
support for Ultra DMA/66 IDE hard drive and a CD-ROM drive
support for PIO mode 3 and mode 4
Diskette drive supports 1.44-MB diskette drive; 34-pin connector
PCMCIA CardBus support for two PC card slots (Type II and Type III
PC cards)
RJ-45 LAN connector.
Video Memory
Standard video memory shared with system memory. Memory
allocation controlled by Dynamic Video Memory Technology (DVMT).
