Configuring the System 3-15
Advanced Menu
Menu Item Settings (default is bold)
I/O Device Configuration Press
Enter
to access the following
submenus.
Serial Port A Disabled,
Enabled
, Auto
Setting at Enabled allows the user to
configure the port.
Setting at Auto enables the BIOS or
operating system to configure the port.
Base I/O Address
3F8
, 2F8, 3E8, 2E8
Selects the base I/O address for serial
port A.
Interrupt IRQ3,
IRQ4
Selects the IRQ for serial port A.
Parallel Port Disabled,
Enabled
, Auto
Setting at Enabled allows the user to
configure the port.
Setting at Auto enables the BIOS or
operating system to configure the port.
Mode Output Only,
Bi-directional
, ECP
Selects parallel port mode.
Base I/O Address
378
, 278, 3BC
Selects the base I/O address for the LPT
port.
Interrupt IRQ5,
IRQ7
Selects the IRQ for the LPT port.
