Finishing the Installation
3-6 ◆ Section 3: Installing Extensions and Trunks DS2000 Hardware Manual
Reinstalling the Front Cover
To reinstall the front cover (Figure 3-7):
1. Hook the tabs on the rear of the cover into their associated slots.
2. Push the front of the cover into place.
3. Screw in the two captive screws that secure the cover to the cabinet.
Figure 3-7: Reinstalling the Front Cover
80000 - 12 A
4 Slot Cabinet Shown
