Electra Elite IPK Document Revision 2a
System Hardware Manual 2 - 9
___________________________________________________________________________________
___________________________________________________________________________________
H Once the appropriate selections have been made, click the
Update button to update the Elite LAN PC Programming
Device with the new settings.
 The Ping option can be used to verify that the device is
able to be reached, the Factory Default button is used to
restore the unit back to default settings.
Once the configuration has be accepted, a confirmation letting
you know that the device was configured successfully appears.
H Click the OK button, and then close the IP Connection Setup
window.
H Now you are ready to connect to the Elite IPK System by using
the Connect Screen.
Figure 2-9 Successful Configuration Screen
Figure 2-10 Connect Screen
