Electra Elite IPK Document Revision 2a
System Hardware Manual 2 - 15
___________________________________________________________________________________
___________________________________________________________________________________
SECTION 8TOOLBAR
Several icons are provided to allow the user to navigate the program. The icons in
the toolbar are explained in this section The availability of the individual tools
depends on the activity the user is performing. When the icon appears shadowed,
the tool is not available. When the icon is dark, the tool is available. Refer to Figure
2-14 Electra Elite IPK/Electra Elite System Administration Terminal Software Screen
Samples for an example.
Accesses the Job Specifications printing option.
Accesses the wizard for individual features. The F10
special function key provides a shortcut to this
wizard.
Sets the defaults for all items on the open tab.
Sets the defaults for the individual system data items
(on the screen the default is set for the item where
the cursor is blinking).
Allows data items to be copied between ports. The
F3 special function key provides a shortcut to this
feature.
Allows values between two ports to be swapped. The
F5 special function key provides a shortcut to this
feature.
Allows the user to undo the current edits and return
to the previous editing operation.
Allows the user to return to the previous editing
operation. The F11 special function key provides a
shortcut to this feature.
