43
1.
(3)
Select
Display
.
Select an item by one of the following operations.
❍
Highlight an item by using
, an
d press
,
or
OK
.
❍
Press
.
(4)
Select
Calendar Format
.
Select an item by one of the following operations.
❍
Highlight an item by using
, and press
,
or
OK
.
❍
Press
.
(5)
Select
Time Format
.
3
3
1
1
2
56
58
