English-18

Basic Operation -Power ON and OFF Modes

1. Pressing the power button.

NOTE: Before pressing the power button, be sure to turn on

the Main Power Switch on the LCD monitor.

2. Using the remote control

NOTE: Before operating the remote control, be sure to turn

on the Main Power Switch on the LCD monitor.

3. Pressing the Main Power Switch.

NOTE: When the Main Power Switch is used to power off

the LCD, the remote control and the power button will not ac-

tivate the LCD and both green and red Power indicators turn

off. Be sure to turn the Main Power Switch to “ON” before

using options 1 or 2.

The LCD monitor power indicator will turn green while powered on and will turn red while powered off. The monitor can be powered on

or off using the following three options:

Power Button

Main Power Switch

REMOTE

CONTROLLER RU-M104

When Using Power Management Function

Selecting a Video Source

Picture Size

Questions and Answers:

Need help?

Do you have a question about the NEC MultiSync LCD3210 and is the answer not in the manual?

NEC MultiSync LCD3210 Specifications

General

I/O ports	1 x D-sub 15 pin in/out 5 x BNC 1 x Cinch out 2 x Cinch in
Pixel pitch	0.511 x 0.511 mm
Power requirements	100-120 V/220-240 V; 1.4 A/0.6 A
Vertical scan range	58 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Headphone connectivity	3.5 mm
Operating relative humidity (H-H)	20 - 80 %
Response time	18 ms
Display diagonal	32 \
Display brightness	500 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	800 mm
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Operating temperature (T-T)	5 - 40 °C
Certification	CE; TÜV GS; C-tick; FCC Class B; UL/C-UL or CSA; CCC; PSB; VCCI; Ro
RS-232 ports	1
Product color	Silver
Panel mounting interface	600 x 200 mm
Power consumption (typical)	110 W
RMS rated power	14 W
Number of speakers	2

Weight and Dimensions
