4) Diamond Scan 51 Different List
ASSY CODE PART NO DESCRIPTION LOCATION Q'TY ALT REMARK
1 CABINET FRONT ASSY 10100721 CABINET FRONT 1
2 CABINET FRONT ASSY 11300481 PUSH BUTTON(FUNCTION) 1
3 CABINET FRONT ASSY 11300491 PUSH BUTTON(SW) 1
4 CABINET FRONT ASSY 11600181 LENS 1
5 CABINET FRONT ASSY 13000061 COIL SPRING 1
6 PACKING ASSY 80001651 POWER CORD 3P 1.8M EUROPE
POWER CORD
1
7 PACKING ASSY 11000331 REVOLVING STAND ASSY 1
8 PACKING ASSY 13200911 CARTON BOX DS51(B) 1
9 PACKING ASSY 13400251 POLYLON(L)CARTON 1
10 PACKING ASSY 13400261 POLYLON(R)CARTON 1
11 PACKING ASSY 13700021 BAG POLYETHYLENE (270*370) 1
12 PACKING ASSY 13700031 BAG POLYETHYLENE (150*370) 1
13 PACKING ASSY 13700071 PE POLYETHYLENE (500*480*850+W) 1
14 PACKING ASSY 13700091 BAG POLYETHYLENE (360*360) 1
15 PACKING ASSY 15500681 OWNERS MANUAL DS51(B) 1
16 PACKING ASSY 15200281 LABLE,SERIAL BARCODE(A) 1
17 PACKING ASSY 11000381 REVOLVING STAND ASSY OR
18
REVOLVING STAND ASSY
17000291 CUSHION SHEET FOR BASE 4
19
REVOLVING STAND ASSY
17000451 CUSHION SHEET FOR BASE 4
20
REVOLVING STAND ASSY
11000251 REVOLVING STAND(B)(94HB) 1
21
REVOLVING STAND ASSY
11000261 REVOLVING STAND(T)(94HB) 1
22
REVOLVING STAND ASSY
11000361 REVOLVING STAND(B)(94HB) 1
23 SET ASSY 80009271 SIGNAL CABLE 20276 1.5M FOR N9701 VE CABLE 1
24 SET ASSY 80005211 TOSHIBA M36LGE23X205(F1M1) CRT 1 T
25 SET ASSY 80011191 15" ORION M36QCZ100XX41 CRT 1 O
26 SET ASSY 80010481 15" N0501 MPRII DEGAUSSING
DEGUESSING
COIL
1T
27 SET ASSY 80011221 15" MPRII DEGAUSSING FOR ORION/LG
DEGUESSING
COIL
1O
28 SET ASSY 14000011 SCREW (#2CBRITS*4*16*15BF)
FOR BACK
2
29 SET ASSY 14000071 SCREW (PL-CPTS3*8*15BF)
FOR BKT-CAB
2
30 SET ASSY 14300031 SCREW (PL-CPIMS*4*10*15BF)
FOR BKT-CAB
2
31 SET ASSY 14600011 SCREW SPECIAL (5*25) FOR CRT 4
32 SET ASSY 17000111 CRT PAD t=3.5 FOR CRT 4
33 SET ASSY 18000281 FIXED CABLE CLIP(GL-70A)
FOR DEGUES
2
34 SET ASSY 18000351 FIXED CABLE CLIP(GL-140A)
FOR DEGUES
2
35 SET ASSY 11700211 SUPPORT
FOR FRONT
2
36 SET ASSY 14000021 SCREW (#2CBRITS*4*12*15BF)
FOR FRONT
4
37 SET ASSY 18000271 SPACER SUPPORT(PS-26GD) FOR M/B 4
38 SET ASSY 80010731 GND WIRE BLECK 160mm 18AWG 1015
GND 5,GND7
2
39 SET ASSY 80010721 GND WIRE BLECK 320mm 18AWG 1015 GND 8 1
40 SET ASSY 80010751 V521 CRT GND WIRE GND WIRE 1
41 SET ASSY HB000018 ROTATION COIL 200TN ROTATION 1
42 SET ASSY 17000351 CUSHION PIECE(BACK) SPONGE 1
43 SET ASSY 17000321 CABLE TIES(GT-100M) TIE 9
44 SET ASSY 15000891 NAME PLATE INSTRUCTION DS51(B) 1
45 SET ASSY 15200471 LABLE WARNING (27.5KV/600uA) 1
46 SET ASSY 15200031 LABEL (REV.) 1
47 SET ASSY 10100701 CABINET FRONT ASSY 1
48 SET ASSY 10101581 CABINET BACK 1
49 SET ASSY 12000551 BRACKET (CABLE) 1
50 SET ASSY 12300202 PLATE SHIELDING (VIDEO) 1
51 SET ASSY 18000261 ANODE CLAMPER(SPA-11G) 1
52 SET ASSY 18000421 SWITCH EXPANDING COVER 1
REVISED BY ECN: NN1040009
SORT BY ASSY CODE
98
T: Toshiba, O: Orion
To Next Page
