NEC MultiSync V520 Service Manual

SPECIFICATION
NOTE: Technical specifications are subject to change without notice.
Monitor
Specifications
N0501
Monitor
Notes
Picture Tube Dia
g
onal:
Viewable Ima
g
e Size:
Radius:
38cm(15inch)
35cm(13.8inch)
1080mm
90° deflection, 0.28mm trio dot pitch, medium
short persistence phosphor, multi-layered, anti-
static screen coating, semi-tint screen, Invar
Shadow Mask.
Input Si
g
nal Video:
S
y
nc:
ANALOG 0.7Vp-p/75 Ohms
Separate sync. TTL Level
Horizontal sync. Positive/
Negative
Vertical s
y
nc. Positive/Ne
g
ative
Displa
y
Colors Analo
g
input: Unlimited number of Colors Depends on display card used.
Synchronization
Range
Horizontal:
Vertical:
31 kHz to 70 kHz
55 Hz to 120 Hz
Automatically
Automatically
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
640
×
480 @ 60 to 120 Hz
800
×
600 @ 55 to 110 Hz
832
×
624 @ 55 to 106 Hz
1024
×
768 @ 55 to 87 Hz ……
1152
×
870 @ 55 to 77 Hz
1280
×
1024 @ 55 to 66 Hz
Some s
y
stems ma
y
not support all modes listed.
NEC cites recommended resolution at 85 Hz for
optimal display performance.
Active Displa
y
Area
(
Factor
y
Settin
g)
Horizontal:
Vertical:
270mm
203mm
Dependent upon signal timing used,
and does not include border area.
Active Display Area
(Full Scan)
280mm
210mm
Dependent upon signal timing used,
and does not include border area.
Power Supply AC 100 - 240V, 50 - 60Hz
Current Rating 1.3A @ 100 - 240V
Dimensions 360
(
W
)
×
380
(
H
)
×
381
(
D
)
mm
Weight (Net) 12.5 kg
Environmental Considerations
Operatin
g
Temperature:
Humidit
y
:
Altitude:
Stora
g
e Temperature:
Humidit
y
:
Altitude:
0° C to + 35° C
30% to 80%
0 to 3000 m
-20° C to + 60° C
10% to 90%
0 to 13700 m
3
