3. VIDEO NOISE, UNSYNCHRONOUS
CHECK HORIZONTAL
FREQUENCY C114 TO GND
CHECK
Q101 G-S FREQUENCY
SYNCRONIZE
WITH H-SYNC
CHECK HORIZONTAL
FREQUENCY C132 TO GND
CHECK C132, R139,
D115, R138, R140
NORMAL OPERATION
CHECK
Q101 G-S FREQUENCY
SYNCRONIZE
WITH H-SYNC
CHECK C114, R116
D109, R115, R117
YES
YES
NONO
NONO
