NEC MultiSync V520 Service Manual

Replacement Parts List
1) MultiSync V520 Parts List
B: Asia, C: China, R: Australia, T: Toshiba, L: LG, O: Orion
74
ASSY CODE PART NO DESCRIPTION LOCATION Q'TY ALT REMARK
1 CABINET FRONT ASSY 10100552 CABINET FRONT 1
2 CABINET FRONT ASSY 11300351 PUSH BUTTOM(A)-FUCTION KEY 1
3 CABINET FRONT ASSY 11300781 PUSH BUTTOM(A)-POWER KNOB 1
4 CABINET FRONT ASSY 11600121 LENS 1
5 CABINET FRONT ASSY 13000061 COIL SPRING 1
6 CRT BOARD A/I 80000561 BEAD 3.5x6x0.8/T B201 1
7 CRT BOARD A/I 80000561 BEAD 3.5x6x0.8/T B208 1
8 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C201 1
9 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C202 1
10 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C203 1
11 CRT BOARD A/I GB210458 CERAMIC Y5V/T 0.1u/50V Z C204 1
12 CRT BOARD A/I GB210458 CERAMIC Y5V/T 0.1u/50V Z C205 1
13 CRT BOARD A/I GA310655 ELECT 85oC/T 10u/50V M C206 1
14 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C207 1
15 CRT BOARD A/I GA322725 ELECT 85oC/T 220u/16V M C209 1
16 CRT BOARD A/I GA310655 ELECT 85oC/T 10u/50V M C210 1
17 CRT BOARD A/I GA410575 ELECT NP/T 1u/100V M C213 1
18 CRT BOARD A/I GA210575 ELECT 105oC/T 1u/100V M C214 1
19 CRT BOARD A/I GA310655 ELECT 85oC/T 10u/50V M C230 1
20 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C231 1
21 CRT BOARD A/I GA410575 ELECT NP/T 1u/100V M C233 1
22 CRT BOARD A/I GA210575 ELECT 105oC/T 1u/100V M C234 1
23 CRT BOARD A/I GA310655 ELECT 85oC/T 10u/50V M C250 1
24 CRT BOARD A/I GA410575 ELECT NP/T 1u/100V M C253 1
25 CRT BOARD A/I GA210575 ELECT 105oC/T 1u/100V M C254 1
26 CRT BOARD A/I GB210458 CERAMIC Y5V/T 0.1u/50V Z C267 1
27 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C270 1
28 CRT BOARD A/I GE210252 PLASTIC PEI/T 0.001u/50V J C271 1
29 CRT BOARD A/I GB7471F3 CERAMIC Y5P(B)/T 470P/500V K C272 1
30 CRT BOARD A/I GB7102F3 CERAMIC Y5P(B)/T 1000P/500V K C275 1
31 CRT BOARD A/I GB7102H3 CERAMIC Y5P(B)/T 1000P/1KV K C276 1
32 CRT BOARD A/I GB7102F3 CERAMIC Y5P(B)/T 1000P/500V K C278 1
33 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C280 1
34 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C281 1
35 CRT BOARD A/I GB210458 CERAMIC Y5V/T 0.1u/50V Z C282 1
36 CRT BOARD A/I GB210458 CERAMIC Y5V/T 0.1u/50V Z C283 1
37 CRT BOARD A/I GB210458 CERAMIC Y5V/T 0.1u/50V Z C284 1
38 CRT BOARD A/I GA347625 ELECT 85oC/T 47u/16V M C285 1
39 CRT BOARD A/I GB7102F3 CERAMIC Y5P(B)/T 1000P/500V K C287 1
40 CRT BOARD A/I GA347625 ELECT 85oC/T 47u/16V M C289 1
41 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C291 1
42 CRT BOARD A/I GA310655 ELECT 85oC/T 10u/50V M C292 1
43 CRT BOARD A/I GA310655 ELECT 85oC/T 10u/50V M C293 1
44 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C294 1
45 CRT BOARD A/I GE210352 PLASTIC PEI/T 0.01u/50V J C295 1
46 CRT BOARD A/I GE210352 PLASTIC PEI/T 0.01u/50V J C296 1
47 CRT BOARD A/I GB7102F3 CERAMIC Y5P(B)/T 1000P/500V K C297 1
48 CRT BOARD A/I GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C299 1
49 CRT BOARD A/I 72000291 PN9501 CRT BOARD(22.5D NECK)
CRT BOARD
1
50 CRT BOARD A/I EJAC0018 DIODE/T 1A 1N4937 D201 1
51 CRT BOARD A/I EJ044148 DIODE "T" 1N4148 D202 1
52 CRT BOARD A/I EJ044148 DIODE "T" 1N4148 D203 1
