3) MultiSync MV521 Different List
ASSY CODE PART NO DESCRIPTION LOCATION Q'TY ALT REMARK
1 CABINET FRONT ASSY 10101032 CABINET FRONT(PC+ABS) 1
2 CABINET FRONT ASSY 11300351 PUSH BUTTOM(V)-FUCTION KEY 1
3 CABINET FRONT ASSY 11300781 PUSH BUTTOM(SW)-POWER KNOB 1
4 CABINET FRONT ASSY 11600121 LENS(V) 1
5 CABINET FRONT ASSY 13000061 COIL SPRING 1
6 PACKING ASSY 13700091 BAG POLYETHYLENE (360*360)
FOR Ball&Base
1
7 PACKING ASSY 80001651 POWER CORD 3P 1.8M EUROPE
POWER CORD
1
8 PACKING ASSY 11000341 AUDIO BASE ASSY 1
9 PACKING ASSY 13200881 CARTON BOX V521-1 (B) 1
10 PACKING ASSY 13400571 POLYLON(L)CARTON 1
11 PACKING ASSY 13400581 POLYLON(R)CARTON 1
12 PACKING ASSY 13700021 BAG POLYETHYLENE (270*370) 1
13 PACKING ASSY 13700031 BAG POLYETHYLENE (150*370) 1
14 PACKING ASSY 13700071 PE BAG (500*480*850 + WARNING) 1
15 PACKING ASSY 15500661 OWNERS MANUAL V521/V921-1 (B) 1
16 PACKING ASSY 15500671 MANUAL (AUDIO BASE) 1
17 PACKING ASSY 15900051 SALES OFFICE LIST 1
18
REVOLVING STAND ASSY
17000441 CUSHION PIECE (BACK)80*60*30 FOR BASE 4
19
REVOLVING STAND ASSY
11000261 REVOLVING STAND(T) 1
20
REVOLVING STAND ASSY
11000311 REVOLVING STAND (B) PC+ABS 1
21
REVOLVING STAND ASSY
11000321 COVER STAND(MA) PC+ABS 1
22 SET ASSY 80005101 WIRE 40mm 1618 BK A 1
23 SET ASSY 80009271 SIGNAL CABLE 20276 1.5M FOR N9701 VE CABLE 1
24 SET ASSY 80005181 15" TOSHIBA M36LGE128X205(F1M1) CRT 1 T
25 SET ASSY 80010851 15" LG CRT M36QBX801X04(A) CRT 1 L
26 SET ASSY 80011191 15" ORION M36QCZ100XX41 CRT 1 O
27 SET ASSY 80010491 15" N0501 TCO DEGAUSSING
DEGUESSING
COIL
1T
O
28 SET ASSY 80011231 15" MPRII DEGAUSSING FOR ORION/LG
DEGUESSING
COIL
1L
29 SET ASSY 14000011 SCREW (#2CBRITS*4*16*15BF) FOR BACK 2
30 SET ASSY 18000261 ANODE CLAMPER FOR CRT 2
31 SET ASSY 14600011 SCREW SPECIAL (5*25) FOR CRT 4
32 SET ASSY 17000111 CRT PAD t=3.5 FOR CRT 4
33 SET ASSY 12300202 PLATE SHIELDING (VIDEO)
FOR CRT PCB
1
34 SET ASSY 18000281 FIXED CABLE CLIP(GL-70A)
FOR DEGUES
2
35 SET ASSY 18000351 FIXED CABLE CLIP(GL-140A)
FOR DEGUES
2
36 SET ASSY 17000571 MAYLAR SHEET (CU)
FOR FBT
BOTTOM
1
37 SET ASSY 14000071 SCREW (PL-CPTS*3*8*15BF)
FOR FBT HEAT
SINK
1
38 SET ASSY 11700221 SUPPORT
FOR FRONT
2
39 SET ASSY 14300031 SCREW (PL-CPIMS*4*10*15BF) FOR GND 2
40 SET ASSY 80005101 WIRE 40mm 1618 BK
FOR MAYLAR
SHEET
1
41 SET ASSY 12000551 BRACKET CABLE
FOR SIGNAL
1
42 SET ASSY 14000021 SCREW (#2CBRITS*4*12*15BF)
FOR SUPPORT
4
43 SET ASSY 80010731 GND WIRE BLECK 160mm 18AWG 1015
GND 5,GND7
2
44 SET ASSY 80010721 GND WIRE BLECK 320mm 18AWG 1015 GND 8 1
45 SET ASSY 80010751 V521 CRT GND WIRE GND WIRE 1
46 SET ASSY 18000361 HOLDER PCB FOR TCO (CBS-50) HOLDER 4
47 SET ASSY HB000018 ROTATION COIL 200TN ROTATION 1
48 SET ASSY 17000351 CUSHION PIECE (BACK)80*60*30 SPONGE 1
49 SET ASSY 72000671 TCO BOARD 250X52.5mm TCO PCB 1
50 SET ASSY 10100913 CABINET BACK 1
51 SET ASSY 10101022 CABINET FRONT ASSY 1
52 SET ASSY 15000861 NAME PLATE INSTRACTION V521-1( B) 1
53 SET ASSY 15200031 LABEL (REV.) 1
B: ASIA, R: Australia, L: LG, T: Toshiba, O: Orion
