NEC MultiSync V520

Cabinet Back
1.Turn the monitor CRT face down on a clean static
free surface to prevent scratching CRT face.
2.Remove the screw “b”.
3.Raise the signal cable vicinity of a cabinet back
and lightly hit part (figure 1 reference) of a top of
the cabinet back and remove the cabinet back.
Cabinet Back
Screw “b”
Hitting Position
Cabinet Back
Fig. 1
