NEC MultiSync V520 Service Manual

76
106 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 15mm J27 1
107 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J28 1
108 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J29 1
109 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J3 1
110 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J30 1
111 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J31 1
112 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J32 1
113 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J35 1
114 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J37 1
115 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J4 1
116 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 12.5mm J5 1
117 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J6 1
118 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J7 1
119 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J8 1
120 CRT BOARD A/I R0319110 JUMPER WIRE AI/T 7.5mm J9 1
121 CRT BOARD A/I FA040473 CARBON 1/8W(T) 5% 47Kohm JP1 1
122 CRT BOARD A/I HB013828 PACKING COIL /T 0.82uH K(EC24) L203 1
123 CRT BOARD A/I HB013828 PACKING COIL /T 0.82uH K(EC24) L204 1
124 CRT BOARD A/I HB013828 PACKING COIL /T 0.82uH K(EC24) L205 1
125 CRT BOARD A/I HC006002 BEAD 3.5X4.7/T L206 1
126 CRT BOARD A/I EAA12133 TR NPN 2SC1213AC TO-92(T) Q201 1
127 CRT BOARD A/I FA040221 CARBON 1/8W(T) 5% 220ohm R201 1
128 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R202 1
129 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R203 1
130 CRT BOARD A/I FA040472 CARBON 1/8W(T) 5% 4.7Kohm R204 1
131 CRT BOARD A/I FA040152 CARBON 1/8W(T) 5% 1.5Kohm R205 1
132 CRT BOARD A/I FA240103 CARBON 1/4W(T) 5% 10Kohm R206 1
133 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R208 1
134 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R209 1
135 CRT BOARD A/I FB247509 METAL 1/4W(T) 1% 75ohm R210 1
136 CRT BOARD A/I FA040330 CARBON 1/8W(T) 5% 33ohm R211 1
137 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R212 1
138 CRT BOARD A/I FA040391 CARBON 1/8W(T) 5% 390ohm R213 1
139 CRT BOARD A/I FA040333 CARBON 1/8W(T) 5% 33Kohm R219 1
140 CRT BOARD A/I FA240151 CARBON 1/4W(T) 5% 150ohm R220 1
141 CRT BOARD A/I FA040111 CARBON 1/8W(T) 5% 110ohm R221 1
142 CRT BOARD A/I FA040224 CARBON 1/8W(T) 5% 220Kohm R223 1
143 CRT BOARD A/I FB247509 METAL 1/4W(T) 1% 75ohm R230 1
144 CRT BOARD A/I FA040330 CARBON 1/8W(T) 5% 33ohm R231 1
145 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R232 1
146 CRT BOARD A/I FA040391 CARBON 1/8W(T) 5% 390ohm R233 1
147 CRT BOARD A/I FA040333 CARBON 1/8W(T) 5% 33Kohm R239 1
148 CRT BOARD A/I FA240151 CARBON 1/4W(T) 5% 150ohm R240 1
149 CRT BOARD A/I FA040111 CARBON 1/8W(T) 5% 110ohm R241 1
150 CRT BOARD A/I FA040224 CARBON 1/8W(T) 5% 220Kohm R243 1
151 CRT BOARD A/I FB247509 METAL 1/4W(T) 1% 75ohm R250 1
152 CRT BOARD A/I FA040330 CARBON 1/8W(T) 5% 33ohm R251 1
153 CRT BOARD A/I FA040101 CARBON 1/8W(T) 5% 100ohm R252 1
154 CRT BOARD A/I FA040391 CARBON 1/8W(T) 5% 390ohm R253 1
155 CRT BOARD A/I FA040333 CARBON 1/8W(T) 5% 33Kohm R259 1
156 CRT BOARD A/I FA240151 CARBON 1/4W(T) 5% 150ohm R260 1
157 CRT BOARD A/I FA040111 CARBON 1/8W(T) 5% 110ohm R261 1
158 CRT BOARD A/I FA040224 CARBON 1/8W(T) 5% 220Kohm R263 1
