NEC P506QL - Top View

1 Getting Started
– 3 –
Top view
1
2
3
4
5 6
ITEM
LABEL
DESCRIPTION
SEE PAGE
1.
POWER Indicator
Display the power on/off sequence status.
48
2.
STATUS Indicator
Display the status of projector.
3.
Light Indicator
Display the light source status.
4.
Temp Indicator
Display the thermal status.
5.
Vertical Lens Shift
(UP / DOWN)
Adjusts the image position vertically.
16
6.
Horizontal Lens Shift
(LEFT / RIGHT)
Adjusts the image position horizontally.
16
