2-6 SVP Server Overview
SVP Server Installation, Setup, & Maintenance Manual - Revision 1
Figure 2-2
Telephony Gateway System Example
System Components
System components are discussed in the following sections:
• MH110 and MH120 Wireless Telephones
• Telephony Gateway
• Access Points
• Ethernet Switch
• Router
• SVP Server
• Administrative computer
• TFTP Server
Administrative
Computer
SVP Server
Ethernet Switch
Telephony Gateway
Telephony Gateway
Telephony Gateway
Telephony Gateway
Telephony Gateway
Demarc Block
PBX
Device supplied by
NEC Business Solutions Ltd
CAT 5 cable
25 pair cable
Multiple phone cables
Phone cable
access point
access point
Optional
Wireless
POS
