Necta Brio 250 - Wiring Diagram

© by NECTA VENDING SOLUTIONS SpA 0308 162-00
INITIALS DESCRIPTION
WIRING DIAGRAM LEGEND
INITIALS DESCRIPTION
33
BDV BDV COIN MECH CONNECTORS
BFL LIQUID WASTE TRAY SWITCH
CCG GENERAL COUNTER
CM1-2 MICROSWITCH FOR BREW UNIT MOTO
CM3 CUP TRAY MICROSWITCH
CMCB CUP CONTAINER MOTOR MICROSW.
CMSB CUP RELEASE MOTOR CAM
CV VOLUMETRIC COUNTER
E1-... INSTANT SOLENOID VALVE
EEA WATER INLET SOLENOID VALVE
ER COFFEE DISPENSER SOLENOID VALV
ESC COFFEE RELEASE MAGNET
EX EXECUTIVE COIN MECH CONNECTOR
FA RADIO INTERFERENCE SUPPRESSOR
FREE FREE VENDING SWITCH
FS1-.. FUSE
ID COFFEE DOSE SWITCH
IMSP STIRRER RELEASE MICRO-SWITCH
IP DOOR SWITCH
IPF WASTE CONTAINER OVERFLOW SWIT
IVA EMPTY BOILER MICRO-SWITCH
IVB EMPTY CUP DISPENSER MICRO SWITC
JUG JUG FACILITIES SWITCH
KC1-.. COFFEE BOILER CUTOUT
KS1-.. SAFETY CUTOUT
LF1-.. LAMP
M COFFEE UNIT MOTOR
MAC GRINDER
MD1-.. INGREDIENT MOTOR - INSTANT
MDTE FRESH REA DOSER UNIT
MDZ INGREDIENT MOTOR - SUGAR
MF1-.. WHIPPER MOTORS
MPF PRESH BREW PISTON MOTOR
MSB CUP RELEASE MOTOR
MSCB CUP CONTAINER SHIFT MOTOR
MSP STIRRER RELEASE MOTOR
MSV TRAY MOVING MOTOR
NTC1-. TEMPERATURE PROBE
PD DIODE RECTIFIER
PG UNIT DETECTION MICROSWITCH
PIP PROGRAMMING BUTTON
PL WASH CYCLE BUTTON
PM PUMP
PR PRESSURE SWITCH
PSB CUP RELEASE BUTTON
RCC COFFEE BOILER HEATING ELEMENT
RCS INSTANT BOILER HEATING ELEMENT
RIS COFFEE UNIT HEATER
RT BALLAST
SAL VOLTAGE SUPPLY BOARD
SM CONTROL BOARD
SM2 EXPANSION BOARD
SP PUSH-BUTTON BOARD
ST STARTER
TH THERMOSTAT
TR TRANSFORMER
TR1 TRANSFORMER 230 V 24 V
TX.... DELAYED FUSE (X=COURRENT)
TZ CUP SENSOR
VAR VARISTOR
VENT FAN
