NW Global Vending – TECHNICAL MANUAL
This document was produced by MARK AC for the exclusive use of the technical personnel in the after-sales service.
. No part of this document may be divulged to a third party or reproduced partially or entirely without the prior permission of NW GLOBAL VENDING
. All rights reserved.
New dispenser “KORO” 07/10/2005 page 12 / 42
7 – HYDRAULIC LAYOUT “ESPRESSO”
ESPRESSO VERSION COMPONENTS
N.B. The diagram shown is given only as a reference as it may differ for each version.
REF. DESCRIPTION REF. DESCRIPTION REF. DESCRIPTION
1
Spouts assembly 2 Pump 3 Mixers
4
Boiler assembly 5 Brewer unit 6 Solenoid valve block
7
Bypass 8 Water supply tank 9 Volumetric counter
