New dispenser “KORO” 07/10/2005 page 7 / 42
VISTA
CON PORTA APERTA
2.2 REAR COMPARTMENT WITHOUT PROTECTIVE
CASING
Detail of CPU / actuation machine board
Detail of machine board
(FRESH-BREWER version only)
30
31
32
36
35
37
39
33
34
38
