NW Global Vending – TECHNICAL MANUAL
This document was produced by MARK AC for the exclusive use of the technical personnel in the after-sales service.
. No part of this document may be divulged to a third party or reproduced partially or entirely without the prior permission of NW GLOBAL VENDING
. All rights reserved.
New dispenser “KORO” 07/10/2005 page 9 / 42
3 - LIST OF MAIN COMPONENTS
N° Ref.
DESCRIPTION
1 Lock
2 Cabinet
3 User interface
4 Selection keypad
5 Dispensing unit
6 Dispensing compartment
7 Back protective casing
8 Grid fuses
9 Main switch
10 Water inlet solenoid valve
11 Power supply cable
12 Grinder / doser device
13 Instant product container
14 Mixers
15 Door
16 Coffee beans door
17 Coffee beans hopper
18 Decaf coffee door (powder)
19 Water supply tank (espresso)
20 Drip tray
21 Solid waste container
22 Brewer unit Z3000
23 Coffee container for FB (powder)
24 Instant product container
25 Dispensing compartment
26 Hot water nozzle
27 FB unit SIGMA BREWER
28 Mixers
29 Protective casing
30 Actuation board
31 Steam exhauster
32 Boiler heating element actuation board
33 Grid fuses
34 Main switch
35 Sigma Brewer control board (FB version only)
36 Transformer fuses
37 Transformer
38 Grid noise suppressor
39 Power supply cable clamp
40 Coffee grinder unit
41 Espresso boiler compartment
42 Espresso boiler
43 Electromagnetic pump
44 Open-top boiler (Instant & Fresh brewer)
