Necta Koro - Page 8

NW Global Vending – TECHNICAL MANUAL
This document was produced by MARK AC for the exclusive use of the technical personnel in the after-sales service.
. No part of this document may be divulged to a third party or reproduced partially or entirely without the prior permission of NW GLOBAL VENDING
. All rights reserved.
New dispenser “KORO” 07/10/2005 page 8 / 42
Perspective view without protective casing
Side view without protective casing
– espresso boiler side
Side view without protective casing
open-top boiler side (FB – Instant)
42
40
44
41
43
