New dispenser “KORO” 07/10/2005 page 32 / 42
The mixers are newly designed, although many components are developed from the ones used in previous
models.
More specifically, the release and opening system of the external assembly is new, while the motor and the
water tightness system are identical.
The new system permits easier disassembly for daily cleaning.
For further details and technical information refer to the specific “Service Manual”.
TRAY UNDER THE MIXER BEING REMOVED
MIXER IN EXTRACTION POSITION:
DETAIL OF RELEASE LEVER
PLASTIC COMPONENTS OF DISASSEMBLED MIXER
MIXER HAVING THE EXTERNAL PARTS THAT NEED
DAILY HYGIENE BEING REMOVED
