New dispenser “KORO” 07/10/2005 page 13 / 42
INSTANT VERSION COMPONENTS
N.B. The diagram shown is given only as a reference as it may differ for each version.
8 – HYDRAULIC LAYOUT INSTANT
REF. DESCRIPTION REF. DESCRIPTION REF. DESCRIPTION
1
Spouts assembly 2 Mixers 3 Solenoid valves
4
Boiler assembly 5 Water supply pump 6 Water supply tank
2
1
6
5
4
3
