NW Global Vending – TECHNICAL MANUAL
This document was produced by MARK AC for the exclusive use of the technical personnel in the after-sales service.
. No part of this document may be divulged to a third party or reproduced partially or entirely without the prior permission of NW GLOBAL VENDING
. All rights reserved.
New dispenser “KORO” 07/10/2005 page 14 / 42
9 – HYDRAULIC LAYOUT “FRESH BREWER”
COMPONENTI VERSIONE FRESH BREWER
N.B. The diagram shown is given only as a reference as it may differ for each version.
REF. DESCRIPTION REF. DESCRIPTION REF. DESCRIPTION
1
Spouts assembly 2 Sigma Brewer boiler 3 Mixer
4
Solenoid valves 5 Boiler 6 Water supply pump
7
Water supply tank 8 9
