SPOUTS ASSEMBLY
Because of the size of the vending machine
FIXED SPOUTS have been designed.
The spouts are mounted onto a tray that is
easy to remove for daily cleaning.
EXTERNAL VIEW OF SPOUTS ASSEMBLY
DETAIL OF SUPPORT TRAY BEING REMOVED
