Appendix A: Installation protocol
Copy the installation protocol, ll it in and save it as a service record.
For values, note the value in the result column, otherwise a tick will sufce if
the item has been performed or considered.
NOTE! If a value is outside the limit or a result is incorrect or missing, this is
to be rectied before the initial start-up and normal operation.
Correct limits or results are given within brackets.
E-PAK DX No. Date:
Performed by:
Control items Result
Application requirements (limits)
Installation area classication
Material MIE (>3 mJ)
Material MIT (>205 ºC)
Material Kst (<200 bar m/s)
Material Pmax (<10 bar (145 PSI))
Material chemical/thermal reaction risk
Radiation heat from surroundings
Delivery checks
Missing components
Transport damage
Before installation
Foundation
Traction forces (2.5 kN horizontally, 6.5 kN vertically)
Total weight (194/235/360 kg (428/518/794 lb))
Anchor bolts (Hilti HDA-PF 20-M10×100/20)
Flame and pressure risk area clear
Access for maintenance/lter replacement (1 m above unit)
Mounting (check availability)
Maintenance switch
Installation room, ventilation openings
Antistatic plastic bag
