E-PAK 150 DX/300 DX/500 DX
49
EN
Control items Result
Duct system
PS cable (optional)
Start and control unit, terminals 3–4
Duct system
Duct dimensioning/transport velocity, check performance
Pressure resistant duct
Isolation device
Electrical installation
Connections – Start and control unit
Connection – GND1
Connection – power cable, check tightness
Lightning conductor
Compressed air
Air lines cleaned
Air pressure (6–10 bar, 87–145 PSI)
Clean and dry air (ISO 8573-1, class 5)
Compressed air valve
Compressed air connected to unit
Ground check measurement
Check (≤100 ohm):
• GND1 – Filter bags
• GND1 – Explosion relief panel
• GND1 – Inlet
• GND1 – Collector bin
• GND1 – Fan
Check (≤10
5
ohm):
• Incoming duct – Incoming mains ground
• GND1 – External mains ground
Accessories (if applic able)
