HV Control PanelEN
22
6.6.2 SSR DIR Service mers
WhenthePilotsignalisdeacvatedoraerpressingtheTeststartbuon,theSSRandDIR
mersarestartedinparallel.
SSR stop delay
SSRisthemetheunitwillconnuetorunwithoutthePilotsignal,oraerpressingthe
Teststartbuon.WhentheSSRmeexpires,thesystemgoesfromRunningtoStandby
mode.ToavoidfrequentStart/Stop,SSRrangeissettoaminimumofsixminutes.
Sengs Range Default Used
SSR 6-9999 m 30
DIR(onlyvisibleforRBU) 0-999 s 20
VAC/RBUselecon VAC
Serviceinterval 0-9999h 2000
DIR Idling delay
DIRisthedelaybeforethestart-upvalveisdeacvated,i.e.,itgoestoIdlingmodeaer
thePilotsignalisdeacvated.ThisisonlyrelevantforanRBUunit,anditisonlydisplayed
whenRBUisselected.
Whencounng,DIRandSSRareresetby:
1. Stopbuonwhenrunning.
2. WhentheWeekmerorOverme/TimerputsthecontrolpanelintoOmode.
Service interval
Serviceintervalsetstheintervalbetweenservice.TheservicemeisdisplayedunderVAC/
RBUandcanbereset.
Reset
PressResetfor5secondstoresettheServicemerto0.
6.6.3 Sengs- Filter Cleaning
Filter Cleaning Range Default Used
Pulse-me
0-99,9s 4
Pause-me 0-999 s 10
Interval1 1-9999 m 60
Interval2 1-9999 m 10
Interval2delay 0-99 s 30
