Nederman HV Control Panel EX Series - Installation Procedures; Mounting Instructions

HV Control Panel
9
EN
Motor size (kW) Supply Voltage (V) Aprox
Motor Current (A)
(I -Nominal)
Hz Recomended
Main Fuse (A)
Motor Overload seng
(A)
45-55 460 68-83 60 90-125
0,58*I-nom
5 Installaon
WARNING! Risk of personal injury.
Alwaysreadsecon3. Safetybeforeinstallaon,use,service,ortroubleshoongofthis
product.
5.1 Delivery check
Ifthereareanydamagedormissingpartswhentheproductisdelivered,nofythecarrier
andthelocalNedermanrepresentaveimmediately.
5.2 Mounng
NOTE! Mounttheproductatanappropriateheightandinaneasilyaccessiblelocaon.
Thisincludesbeingabletoeasilyaccessanylabelsontheproduct.
Followthestepsbelowtomounttheproduct:
1. Installtheglandplatetotheboomoftheproduct.
2. Aachthewallmounngkittotherearmounngplateofthecabinet.
3. MounttheHVControlPanelEXtoawallthatisstrongenoughtosupporttheproduct.
Useappropriateboltsandplugsforthesurface.Theboltsmusteachstandastress
ofatleast1500N.Holesforscrews,maxØ10mm.Seealsoincludedassembly
instrucons.
830 mm (800 x 600 mm cabinet)
544 mm
