Nederman HV Control Panel EX Series User Manual

HV Control Panel
5
EN
WARNING! Risk of personal injury.
•
Onlyproperlytrainedpersonnelareallowedtoinstall,useandservicethisproduct.
• Workwithelectricequipmentistobecarriedoutbyaqualiedelectrician.
• Followalllocalrulesandregulaonsforinstallaon,serviceandtroubleshoongofthis
product.
•
Ifthereisanemergencystoporifthesystemloosespower,anyconnectedpneumac
solenoidvalvecanunexpectedlycauseapartofthesystem,forexampleavalve,to
move.
•
Thisequipmentisdesignedtobeapartofacompletesysteminstallaon.Thedesigner
ofthesystemasawhole,mustguaranteecorrectfunconofallinteracngproducts
orcomponentsandensurethatthecompletesystemmeetsallnecessarysafety
requirements.
•
Supplementaryequipotenalbondingmayberequiredaccordingtolocalregulaons.
• Turnoallpowertotheproductbeforeanymaintenanceandservice.
Table3-1:Explanaonofsignandsckersymbolsusedontheproductcomponentsorwith
documentaon.
Sign Descripon
Riskofelectricshock.Evenwhenthemainswitchisturnedototheproduct,thereissllelectricityinthe
cabinet.Theremayalsobecontrolsignalswithexternalsupply.
CAUTION! Risk of equipment damage.
•
Donotinstalltheproductclosetoheatsources.
• Thisproductisnotintendedforoutdoorinstallaon.
• IftheTransformersupplyvoltagecableisconnectedtothewrongvoltageinput,theHV
ControlPanelEXwillbedamaged.Bydefault,thesupplyvoltagetothetransformeris
connectedto400Vvoltageinput.
• UseonlyNedermanoriginalsparepartsandaccessories.
NOTE!
•
Ifthereisanemergencystop,donotrestarttheproductunltheproblemthatcaused
thealarmiscorrectedandthealarmreset.See 12.1. Alarms. andtheInstallaonand
ServiceManual.Iftheemergencystopbuonwasused,itneedstoberesetbeforethe
alarmcanbereset.
• Ifthereisalossofpower,theproductneedstoberestartedeitherbypressingthestart
buon,viaremote,orbytheWeekmer.TheWeekmercaneitherbesettostartornot
startautomacallyatapower-onduringanacveperiod.
4 Descripon
4.1 Intended use
NOTE! ForFlexFilterEX,usetheHVControlPanelEX.
ThisHVControlPanelEXisintendedforthecontrolandsupervisionofahighvacuum
systemwithNedermanFlexFilterandVACorRBUvacuumsource.
