NESS D16 CONTROL PANEL - USER MANUAL
8
OPERATION
This section describes the operation of a
typical control panel installation. Keep in
mind that your installation may vary
depending on the selected options and
equipment. The operating instructions
which follow will endeavour to cover the
most common options.
Consult your installation company if you
require further information.
All control panel operations are controlled
by the D16 keypad except if an optional key
switch or radio control equipment is
installed.
OPERATING RULES
Generally, the panel will be Disarmed. Armed
or Monitor modes provide different levels of
security for your premises when you are
home or away. Three other temporary
modes; Program, Memory and Exclude, allow
you to perform various operations. The panel
will automatically exit from these temporary
modes if you do not press any buttons on
the keypad in a 4 minute period.
If you make a mistake while entering any
codes, press the enter button and start again.
When you are required to enter your access
code, you are given five opportunities to
enter it correctly. After the fifth invalid
attempt the alarm is activated (requiring the
correct code to silence the alarm). This
prevents anyone trying to guess your code
by entering random numbers.
AREA OPERATION
Area Partitioning allows the 16 zones to be
split into two partitions; Area1 and Area2.
The panel then effectively operates as two
separate systems sharing only the siren
outputs and dialler.
USER CODE ASSIGNMENT
A User Code assigned to an Area can Arm and
Disarm only that Area. User Codes assigned
to both Areas will operate both Areas
simultaneously.
COMMON AREA ZONES
Zones assigned to both Areas are Armed only
when Area1 and Area2 are both Armed. This
allows the Common Area zone/s to be shared
by both Areas.
For example, Office A and Office B operate
as separate areas but the entrance foyer used
by both offices is assigned to both areas
meaning it will automatically Arm when both
Areas have Armed. The Common Area then
automatically disarms when either Area1 or
Area2 Disarms.
OPERATION
Arming and Disarming is carried out as
normal from a single keypad or separate
keypads installed in both areas or by Radio
Key.
Area operation only applies to zones when
they are in the Armed state. This means that
Day, 24hr and Monitor zones are
independent of the area operations.
Note: Area partitioning is in addition to
Monitor Mode. Any zone may be allocated
to any area.
