Ness Pro series - Page 71

71
Figure 8-17: Output Port Tab
5. Select an Output Port; each output port number has a relative camera
number.
6. Tick off “ Enable/Disable” the icon with a tick is “ Enable”
Figure 8-18: Output Port Field
7. Select the “Delay Trigger”, with the unit of seconds, the delay time may
be set from 0 to 999 seconds.
8. Under the “ Active Duration” there are 0 to 999 seconds to choose. The
setting of 0 second means permanent triggering.
9. Then click “Add” , the window below will show “Output Port” with
the selections made.
10. Click “Apply” , and “OK”
Tick off to
“Enable/Disable”
The Delay Trigger
The Active Duration
Note!
An external standard 56K modem is required to transmit
alarm pager trigger, Alarm voice trigger or fax trigger
functions.
