27
A
A. Technical Specifications
The following table lists the technical specifications for the cable modem.
Table 3. Technical specifications
Feature Specification
Power adapter • Input: 1
10–120V, 47–60 Hz
• Output: 12 VDC, 2.5A
Physical specifications • Dimensions: 5.90 x 8.77 x 3.43 in. (149.76 x 222.68 x 87 mm)
• W
eight: 0.84 lb (380 g)
Environmental • Operating temperature: 32° to 104°F (0° to 40°C)
• Operating humidity: 90% maximum relative humidity
, noncondensing
Interface • Local: 10/100/1000 RJ-45 Gigabit Ethernet port
• Internet: Coaxial cable connector
DOCSIS 3.1; backward compatible with DOCSIS 3.0
Memory • 128 MB Flash
• 256 MB RAM
Channels • 2 OFDM and 32 SC-QAM bonded downstream
• 2 OFDMA and 8 SC-QAM bonded upstream
Certifications • CableLabs DOCSIS certified for U.S. cable Internet services
• FCC/UL
