NETGEAR CM1000v2 User Manual

Front panel and LEDs
The cable modem provides status LEDs on the front.
Power LED
Downstream LED
Upstream LED
Online LED
Ethernet LED
Figure 2. Front panel
You can use the LEDs to verify status and connections. The following table lists and
describes each LED on the cable modem.
User Manual6Hardware Setup
High Speed Cable Modem

NETGEAR CM1000v2 Specifications

Power

input voltage	110–120V, 47–60 Hz
output voltage	12 VDC
output current	1.5 A

Operating Environment

operating temperature	32° to 104°F (0° to 40°C)
operating humidity	90% maximum relative humidity, noncondensing

Interface

local ethernet port	One 10/100/1000 RJ-45 Gigabit Ethernet port
internet connector	Coaxial cable connector, DOCSIS 3.1; backward-compatible with DOCSIS 3.0
downstream channels	2 OFDM and 32 SC-QAM bonded

Weight and Dimensions

dimensions	8.8 in x 3.5 in x 5.9 in (223.5 mm x 88.9 mm x 150 mm)
weight	0.95 lb (431 g)
