Table 1. LED descriptions
DescriptionIconLED
•
Solid green. Power is supplied to the cable modem.
•
Off. No power is supplied to the cable modem.
•
Solid red. The cable modem is too warm and might overheat. For
more information about this condition, see Use LEDs to troubleshoot
on page 23.
Power
•
Solid amber. One downstream channel is locked.
•
Solid green. Two or more downstream channels are locked.
•
Blinking green. The cable modem is scanning for a downstream
channel.
•
Off. No downstream channel is locked.
Downstream
•
Solid amber. One upstream channel is locked.
•
Solid green. Two or more upstream channels are locked.
•
Blinking green. The cable modem is scanning for an upstream
channel.
•
Off. No upstream channel is locked.
Upstream
•
Solid green. The cable modem is online.
•
Blinking green. The cable modem is synchronizing with the cable
provider’s cable modem termination system (CMTS).
•
Off. The cable modem is offline.
Online
•
Solid green. A powered-on device is connected to the LAN port at
1000 Mbps.
•
Solid amber. A powered-on device is connected to the LAN port at
10 Mbps or 100 Mbps.
•
Off. No device is connected to the LAN port.
•
Blinking green or amber. The LAN port is processing traffic.
Ethernet
Rear panel
The connections and button on the rear panel are shown in the following figure.
User Manual7Hardware Setup
High Speed Cable Modem

NETGEAR CM1000v2 Specifications

Power

input voltage	110–120V, 47–60 Hz
output voltage	12 VDC
output current	1.5 A

Operating Environment

operating temperature	32° to 104°F (0° to 40°C)
operating humidity	90% maximum relative humidity, noncondensing

Interface

local ethernet port	One 10/100/1000 RJ-45 Gigabit Ethernet port
internet connector	Coaxial cable connector, DOCSIS 3.1; backward-compatible with DOCSIS 3.0
downstream channels	2 OFDM and 32 SC-QAM bonded

Weight and Dimensions

dimensions	8.8 in x 3.5 in x 5.9 in (223.5 mm x 88.9 mm x 150 mm)
weight	0.95 lb (431 g)
