NETGEAR EN104TP User Manual

Model EN104
TP
/EN106
TP
/EN108
TP
Ethernet Hub Installation Guide
Vista 10BASE-T Network Ports with Built-in LEDs
The front panel of the Model EN104
TP
hub has four RJ-45 10BASE-T ports, the
Model EN106
TP
hub has six RJ-45 10BASE-T ports, and the Model EN108
TP
hub has eight RJ-45 10BASE-T ports. Two LEDs—the Link LED and the Rx
LED—are built into each 10BASE-T port.
Product Illustration
8723FA
Front Panel of the Model EN104
TP
hub
Front Panel of the Model EN106
TP
hub
Front Panel of the Model EN108
TP
hub
123456
LINK Rx
Normal/Uplink
Pwr
Col
EN106
TP
10 BASE-T HUB
Pwr
Col
EN104
TP
10 BASE-T HUB
Pwr (Power)
10BASE-T ports
Normal/Uplink
push button
Col (Collision)
LINK Rx
1234 56 78
Pwr
Col
EN108
TP
10 BASE-T HUB
LINK Rx
8724EA
Link
LED
Rx
LED
