S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual119
• Enable. Spanning tree is enabled for this LAG. Enable is the default.
11. From the Link Trap menu, select Enable
or Disable to specify whether to send a trap when
the link status changes.
The default is Enable, which causes the trap to be sent.
12. From the LAG Type menu, select Static or LACP:
•
Static. Disables Link Aggregation Control Protocol (LACP) on the selected LAG. The
LAG is configured manually
. The default is Static.
• LACP. Enables LACP on the selected LAG. The LAG is configured automatically.
13. Click the Apply
button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Table 28. LAG Configuration information
Field Description
LAG ID The identification of the LAG (l1–l8).
Active Ports Indicates the ports that are actively participating in the port channel.
LAG State Indicates whether the link is up or detached.
Configure LAG Membership
You can select two or more full-duplex Ethernet links to be aggregated together to form a link
aggregation group (LAG), which is also known as a port channel. The switch can treat the
port channel as a single link.
To configure LAG membership:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is
password.
The System Information page displays.
5. Select Switching> LAG > Basic > LAG Membership.
