S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure System Information User Manual83
7. Click the Apply button.
Your settings are saved.
View the Supported MIBs
You can view a list of all MIBs that are supported on the switch.
To view the supported MIBs:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is
password.
The System Information page displays.
5. Select System > SNMP > SNMP V1/V2 > Supported MIBs.
The following table describes the SNMP Supported MIBs Status fields.
Table 23. SNMP supported MIBs
Field Description
Name The RFC number if applicable and the name of the MIB.
Description The RFC title or MIB description.

Table of Contents

Other manuals for NETGEAR GS324TP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR GS324TP and is the answer not in the manual?

NETGEAR GS324TP Specifications

General IconGeneral
Switch typeManaged
Quality of Service (QoS) supportYes
Power connectorAC-in jack
SFP module slots quantity2
Installed SFP modules quantity-
Basic switching RJ-45 Ethernet ports quantity24
Number of VLANs256
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Virtual LAN featuresPort-based VLAN, Private VLAN, Voice VLAN
MAC address table16000 entries
DHCP featuresDHCP client
Product colorBlack
Rack mountingNo
Number of fans2 fan(s)
Noise level32.8 dB
Input current5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)229.9 W
Total Power over Ethernet (PoE) budget190 W
Operating temperature (T-T)0 - 45 °C
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth206 mm
Width330 mm
Height43 mm
Weight2690 g
