NETGEAR GS324TP User Manual

S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual125
Reset the VLAN Configuration on the Switch to the Default Settings
If you reset the VLAN configuration on the switch to the default settings, all VLANs that you
added are deleted. (The predefined VLANS are not deleted).
The VLAN default values are as follows:
• All ports are assigned to the default VLAN of 1.
• All ports are configured with a PVID of 1.
• All ports are configured to an
Acceptable Frame
Types value of Admit All Frames.
• All ports are configured with ingress filtering disabled.
• All ports are configured to transmit only untagged frames.
• All dynamic entries are cleared.
To reset the VLAN configuration on the switch to the default settings:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.
5. Select Switching> VLAN > Basic > VLAN Configuration.
You can also select Switching> VLAN >
Advanced > VLAN Configuration.
The VLAN Configuration page displays.
6. Select the
Reset Configuration check box.
7. Click the Apply button.
Your settings are saved. Except for the predefined default VLANs, all VLANs are deleted.
Configure VLAN Membership
To configure VLAN membership:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.

NETGEAR GS324TP Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Port-based VLAN, Private VLAN, Voice VLAN
MAC address table	16000 entries
DHCP features	DHCP client
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Noise level	32.8 dB
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	229.9 W
Total Power over Ethernet (PoE) budget	190 W
Operating temperature (T-T)	0 - 45 °C
Cables included	AC

Weight and Dimensions

Depth	206 mm
Width	330 mm
Height	43 mm
Weight	2690 g
