NETGEAR GS324TP User Manual

S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual158
View the STP Statistics
You can view information about the number and type of bridge protocol data units (BPDUs)
transmitted and received on each port.
To view the spanning tree statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is
password.
The System Information page displays.
5. Select Switching > STP >
Advanced > STP Statistics.
6. Select whether to display physical interfaces, LAGs, or both by clicking one of the following
links above the table heading:
•1 (the unit ID of the switch). Only physical interfaces are displayed.
This is the default
setting.
• LAG
. Only LAGs are displayed.
Designated Cost The cost of the port participating in the STP topology. Ports with a lower cost are
less likely to be blocked if STP detects loops.
Designated Bridge The bridge identifier of the bridge with the designated port. It is made up using
the bridge priority and the base MAC address of the bridge.
Designated Port The port identifier on the designated bridge that offers the lowest cost to the
LAN. It is made up from the port priority and the interface number of the port.
Table 39. MST port status information (continued)
Field Description

NETGEAR GS324TP Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Port-based VLAN, Private VLAN, Voice VLAN
MAC address table	16000 entries
DHCP features	DHCP client
Product color	Black
Rack mounting	No
Number of fans	2 fan(s)
Noise level	32.8 dB
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	229.9 W
Total Power over Ethernet (PoE) budget	190 W
Operating temperature (T-T)	0 - 45 °C
Cables included	AC

Weight and Dimensions

Depth	206 mm
Width	330 mm
Height	43 mm
Weight	2690 g
