S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual169
The System Information page displays.
5. Select Switching> Multicast > IGMP Snooping > IGMP Snooping VLAN Configuration.
The IGMP Snooping VLAN Configuration page displays.
6. Select the check box next to the VLAN ID.
7. Update the values.
8. Click the Apply button.
Your settings are saved.
Disable IGMP Snooping on a VLAN
To disable IGMP snooping on a VLAN:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.
5. Select Switching> Multicast > IGMP Snooping > IGMP Snooping VLAN Configuration.
The IGMP Snooping VLAN Configuration page displays.
6. Select the check box next to the VLAN ID.
7. From the Admin Mode menu, select Disable.
8. Click the Apply button.
Your settings are saved.
Configure a Multicast Router Interface
You can configure an interface as the designated interface to which a multicast router is
connected. All IGMP packets snooped by the switch are forwarded to the multicast router
reachable from the interface. Configuring a multicast router interface is usually not required
because the switch automatically detects the multicast router and forwards IGMP packets
accordingly. This configuration is required only if you want to make sure that the multicast
router always receives IGMP packets from the switch in a complex network.

Table of Contents

Other manuals for NETGEAR GS324TP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR GS324TP and is the answer not in the manual?

NETGEAR GS324TP Specifications

General IconGeneral
Switch typeManaged
Quality of Service (QoS) supportYes
Power connectorAC-in jack
SFP module slots quantity2
Installed SFP modules quantity-
Basic switching RJ-45 Ethernet ports quantity24
Number of VLANs256
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Virtual LAN featuresPort-based VLAN, Private VLAN, Voice VLAN
MAC address table16000 entries
DHCP featuresDHCP client
Product colorBlack
Rack mountingNo
Number of fans2 fan(s)
Noise level32.8 dB
Input current5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)229.9 W
Total Power over Ethernet (PoE) budget190 W
Operating temperature (T-T)0 - 45 °C
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth206 mm
Width330 mm
Height43 mm
Weight2690 g
